Our Capabilities

List of Instruments

List of Machines

ZEISS spectrum 7/10/6

zeiss
Max. Load on Table 600 Kg
X – Axis Travel 700 mm
Y – Axis Travel 1000 mm
Z – Axis Travel 6000 mm

JYOTI VMC NX 4222

Max. Load on Table 37100 Kg
X – Axis Travel 4200 mm
Y – Axis Travel 2760 mm
Z – Axis Travel 800 mm
Spindle Speed 10,000 rpm
Rapid 40 m/min
Cutting Feed 15 m/min
Control SIEMENS
No. of Tools (ATC) 40 Nos.
Table Size 3500 × 2000 mm
NX4222

JYOTI VMC RDX 20 With 5th Axis

RDX-20
Max. Load on Table 400 Kg
X – Axis Travel 820 mm
Y – Axis Travel 510 mm
Z – Axis Travel 510 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 1000 x 530 mm

BFW XTRON 544+ With 4th Axis

Max. Load on Table 250 Kg
X – Axis Travel 500 mm
Y – Axis Travel 450 mm
Z – Axis Travel 400 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 600×450 mm
RDX-20

BFW BMV 50TC With 4th Axis

RDX-20
Max. Load on Table 400 Kg
X – Axis Travel 800 mm
Y – Axis Travel 550 mm
Z – Axis Travel 550 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 1000×510 mm

JYOTI VMC RX 20 With 4th Axis

Max. Load on Table 400 Kg
X – Axis Travel 820 mm
Y – Axis Travel 510 mm
Z – Axis Travel 510 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control SIEMENS
No. of Tools (ATC) 24 Nos.
Table Size 1000 x 530 mm
RX-20

JYOTI VMC 1260 nvu

RDX-20
Max. Load on Table 800 Kg
X – Axis Travel 1200 mm
Y – Axis Travel 600 mm
Z – Axis Travel 600 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 10 m/min
Control SIEMENS
No. of Tools (ATC) 24 Nos.
Table Size 1400 x 600 mm

BFW CHAKRA BMV 60+

Max. Load on Table 400 Kg
X – Axis Travel 1050 mm
Y – Axis Travel 610 mm
Z – Axis Travel 610 mm
Spindle Speed 8,000 rpm
Rapid 25 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 1200×650 mm
RX-20

GLOBAL VMC 800

GLOBAL-VMC-800
Max. Load on Table 400 Kg
X – Axis Travel 800 mm
Y – Axis Travel 550 mm
Z – Axis Travel 550 mm
Spindle Speed 8,000 rpm
Rapid 25 m/min
Cutting Feed 10 m/min
Control SIEMENS
No. of Tools (ATC) 24 Nos.
Table Size 1000×550 mm

YANTRANG VX-500

Max. Load on Table 400 Kg
X – Axis Travel 500 mm
Y – Axis Travel 400 mm
Z – Axis Travel 400 mm
Spindle Speed 8,000 rpm
Rapid 40 m/min
Cutting Feed 15 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 800 x 400 mm
RX-20

JYOTHI TURNING DX-200

GLOBAL-VMC-800
Max. Load on Table 250 Kg
X – Axis Travel 250 mm
Z – Axis Travel 300 mm
Chuck Dia 170 mm
Spindle Speed 4,000 rpm
Rapid 24 m/min
Cutting Feed 5 m/min
Control FUNUC
No. of Tools Turret 8 Nos.
Spindle A2-5

BMTC-45

Max. Load on Table 250 Kg
X – Axis Travel 500 mm
Y – Axis Travel 450 mm
Z – Axis Travel 400 mm
Spindle Speed 8,000 rpm
Rapid 25 m/min
Cutting Feed 10 m/min
Control MITSUBISHI
No. of Tools (ATC) 24 Nos.
Table Size 600×450 mm
BATLIBOI
